Ubiquiti UniFi WiFi 7 Tri-Band Pro In-Wall AP | U7-Pro-Wall

Description

Ubiquiti’s U7-IW-PRO is a Tri-Band, WiFi 7 access point featuring 1x 2.5Gbps Ethernet port as well as 6GHz support for interference-free WiFi in demanding, large scale environments. It delivers an aggregate data rate of up to 10.7Gbps over its 6GHz (2×2 MU-MIMO) 5GHz (2×2 MU-MIMO) and 2.4GHz (2×2 MU-MIMO) bands.

It can be configured and managed with the UniFi Network Application.

*Note: PoE injector not included.

FEATURES

• Antenna Gain: 2.4GHz: 4dBi; 5.8GHz: 5dBi : 6GHz: 6dBi
• Beam-width: 360°
• Data Rate: 2.4GHz: 688Mbps; 5.8GHz: 4.3Gbps ; 6GHz: 5.7Gbps
• Ethernet Ports: 1x 10/100/1000/2500
• Hardware Button: Reset
• Max. Power Consumption: 22W
• Mounting: 1 Gang Electrical Wall Box (Not Included)
• Operating System: UniFi
• Operating Temperature: -30°C to 60°C
• PoE Input: 802.3at or Passive PoE
• PoE Output: None
• Power Input: 802.3at or Passive PoE (Not Included)
• Serial Interface: None
• SIM Slots: None
• Supported Voltage Range: 44 to 57V
• USB Ports: None
• Dimensions: 150 x 103 x 36 mm
• Weight: 580g
